ADC library

Askia Design Controls available by default in our library

In this article

    Open

    • To download the QEX file, click here.
    • Version of the ADC: 2.0.5.

    This control is compatible with open questions. Number minimum of responses : *. Number maximum of responses : *. You can use the following controls : responseblock, label, textbox.

    For details of incorporating the new prompting cababilities added to the Open ADC, then please jump to this article.



    Parameters Type Comments and/or possible value

    Features
    Minimum number of characters number
    Value : 0
    Maximum number of characters number
    Value : 50
    allow respondent to resize Boolean
    Value : false
    Type of input string
    Value : text
    Options : Text area (multi line), Text input (single line), Email address, Password
    Character counter
    Character counting string
    Value : desc
    Options : descending, ascending, none
    Position of the counter string Description : Relatively to the text area
    Value : NE
    Options : North-West, North-East, South-West, South-East
    Font size of the counter relatively to the input number
    Value : 0.5
    Placeholder style
    Placeholder text string Description : Using HTML 5, in modern browser. Helper text shows in the input when it's empty.
    Floating Label Boolean Description : Enable floating label styling
    Value : false
    Options : No, Yes
    Colour of the floating label colour
    Value : 0,0,0
    ColorFormat : rgb
    Styling
    Font size (in px) number
    Value : 30
    Text colour colour
    Value : 0,0,0
    Control horizontal alignment string
    Value : center
    Options : left, center, right
    Maximum width string
    Value : 500px
    Options : 100%, 600px, 500px, 400px, 300px, 200px, 100px
    Text alignment in the area string
    Value : left
    Options : left, center, right
    Opacity number
    Value : 1
    Number of rows number
    Value : 2
    Number of columns number
    Value : 25
    Email validation message string Description : attention, this is not a hard blocker. It will only display an indication on screen. Hard blockers have to be set up via blocking message filters.
    Value : Please provide a valid email address
    Styling default state
    Border colour colour
    Value : 0,96,196
    ColorFormat : rgb
    Background colour colour
    Value : 255,255,255
    ColorFormat : rgb
    Border thickness (in px) number
    Value : 1
    Options : 1px, 2px, 3px, 5px
    Border style string
    Value : solid
    Options : solid, none, dashed
    Border radius (in px) number
    Value : 3
    Border shadow (in px) number
    Value : 0
    Styling when mouse hovers
    Border colour on hover colour
    Value : 0,96,196
    ColorFormat : rgb
    Background colour on hover colour
    Value : 255,255,255
    ColorFormat : rgb
    Border thickness on hover (in px) number
    Value : 1
    Options : 1px, 2px, 3px, 5px
    Border style on hover string
    Value : solid
    Options : solid, none, dashed
    Border radius on hover (in px) number
    Value : 3
    Border shadow on hover (in px) number
    Value : 5
    Styling when clicked
    Border colour on active colour
    Value : 0,96,196
    ColorFormat : rgb
    Background colour on active colour
    Value : 255,255,255
    ColorFormat : rgb
    Border thickness on active (in px) number
    Value : 1
    Options : 1px, 2px, 3px, 5px
    Border style on active string
    Value : solid
    Options : solid, none, dashed
    Border radius on active (in px) number
    Value : 3
    Border shadow on active (in px) number
    Value : 5
